8CHT
Model 8CHT

City E-Bikes & Pedelecs of the e-bike manufaktur:

Are you still switching gears yourself?


Our 8CHT premium model is the first e-bike worldwide to be equipped with the 2-in-1 drive system of the Continental eBike system: the 48V Revolution motor combines the motor and a planetary gear in a compact housing. You have the choice between fully automatic gearshift -  continuously adjustable even under load - or manual gearshift using the Ergon button. The clever 2-in-1 motor is powered by powerful batteries with a capacity of 600 W.

Available with a diamond, trapezoidal or wave frame, the premium e-bike stands out with the futuristic look of its fully integrated frame design and particularly high-quality equipment. E-bike quality at the highest level.

This includes the almost maintenance-free Gates carbon belt system as well as powerful disc brakes from Shimano. The manufacturer list of the rest of the equipment reads like the "who's who" of the component scene: Busch & Müller, Racktime, Levelnine, Humpert, Pletscher, SKS, Hesling, or Ergon

Also with Connect!

For added anti-theft security, the e-bike is also available with our Connect theft deterrent - our clever GPS-based security system that lets you see exactly where your e-bike is at all times.

More about Continental's e-bike motor can be found here.

Frame size

  • Trapez
    • 28" / 45 cm
    • 28" / 50 cm
    • 28" / 55 cm
  • Wave
    • 28" / 45 cm
    • 28" / 50 cm
    • 28" / 55 cm
  • Diamant
    • 28" / cm
    • 28" / 50 cm
    • 28" / 55 cm
    • 28" / 60 cm
Compare »
Frame size Diamant 28": 50, 55, 60 cm
Wave 28": 45, 50, 55 cm
Trapez 28": 45, 50, 55 cm
Drive Unit Continental Revolution, 48 V Mittelmotor, 250 Watt
Display Continental Display incl. Bluetooth
Akku Continental Rahmenakku vollintegriert, 600 Wh, 48 Volt, 12.5 Ah, Unterrohr
max load 140 kg
Frame Aluminium 6061, Continental-Interface
Headset Acros AZX-212 tapered
Fork Rock Shox Federgabel, Paragon Gold Solo Air
Rear derailleur ---
Bremse Shimano Deore (160 mm) Scheibenbremse
Headlight Busch&Müller Lumotec IQ-XS, 70 LUX mit Standlicht
Rear light Busch&Müller Toplight 2C, mit Standlicht
luggage carrier Racktime, strebenlos mit Federklappe
Saddle Selle Royal Essenza
Seat pillar Humpert, Atar, patent, Aluminium, 31,6 mm, 300 mm
Pedal Marwi SP-823 Aluminium
Stand Pletscher Comp Flex, Hinterbauständer
Chain guard Horn Catena 14e
Fender SKS, Kunststoff
Wight 25,9 kg
Handlebar stem Humpert Ergotec Octopus 50, winkelverstellbar, 31,8 mm
Handlebar Levelnine, Trekking, Aluminium, 9°, 660 mm
Handle Herrmans DD37 mit Schraubklemmung
Break lever Shimano Deore, 3-Finger Bremshebel
Tyres Continental Contact Plus City, 47-622, reflex
Produktdatenblatt (PDF)
Vollintegrierter Akku – E-Bike Manufaktur

2 in 1 - drive revolution in 8CHT

Continental has for the first time succeeded in integrating a stepless planetary gearbox into compact engine casing and thus presented a 2-in-1 drive as a world premiere. With this combination, Continental has made the rear shift gearbox superfluous. With our model 8CHT, you have the choice between an automatic circuit - infinitely variable even under load - or manual switching using an Ergon button. The clever 2-in-1 drives are powered by powerful batteries with a capacity of 600 Wh.

Gates Riemen – E-Bike Manufaktur

GATES BELT DRIVES

We have fitted some of our e-bikes with Gates' tried-and-trusted belt drive. As a result, complex lubrication and cleaning of chain and gears is now a thing of the past. This carbon-reinforced alternative to the chain is robust and requires little maintenance. In addition, the lightweight system has an impressively long service life. The lock washers also benefit from this solution: they are placed under less strain than with a chain drive.

Display – E-Bike Manufaktur

Display - everything in view

Lightweight and compact displays combine perfect legibility with ergonomic and intuitive operation. In addition to the display for the support level or charge status of the battery, the display offers numerous functions of a bicycle computer as well as a USB and Bluetooth interface. The clever automatic lighting mode is controlled by an integrated light sensor.

Ausfallende – e-bike manufaktur

DROPOUTS WITH SOPHISTICATED FUNCTION AND HARMONIOUS APPEARANCE

The innovative dropout of our e-bikes offers an integrated mounting for a rear stand. In this way, the support can be installed quickly and easily. In addition, the multi-function drop-out end is equipped with an opening for the gate belt. This means it can be changed in no time at all. Thanks to its tidy appearance, the drop-out is a perfect match for the frame design of the e-bike manufacturer.

Harmonisch integriert – e-bike manufaktur

HARMONICALLY INTEGRATED -
EVEN IN OUR WAVE FRAME

Alongside technology and quality, design is also a key factor in the perfect e-bike! The new 48V e-bike system from our partner Continental ensures a harmonious look as the battery is included within the frame. We have even been able to fully integrate the battery into our Wave frame. A new type of frame construction combined with a low centre of gravity promises optimum stability and ride comfort!
