5NF
5NF
  • Wave 28" / 45 cm
    28" / 50 cm
    28" / 55 cm
  • Diamant 28" / 50 cm
    28" / 55 cm
    28" / 60 cm
Colour:
cremeweiß matt, schwarz matt
Find a dealer Compare

City E-Bikes & Pedelecs of the e-bike manufaktur:

Ideal companion for all rides in urban surroundings.


Futuristic and in matt black or cream white - the 5NF is available in two frame variants and is an ideal companion for all trips in urban surroundings. Thanks to the suspension fork from Suntour, comfortable handles from Ergon and Contact Plus tyres from Continental, the 5NF is also suitable for longer trips.

The Continental 48 V eBike system with 600 Wh battery harmonises perfectly with the Shimano Alfine 8-speed hub circuit and the low-maintenance Gates belt drive.

More about Continental's e-bike motor can be found here.



Also with Connect!

For an increased protection against theft, you can buy this e-bike at an additional charge of 149,- euros and get it with Connect – the clever GPS-based anti-theft device which allows you to know exactly where your e-bike is at all times.

If you want to use Connect, this should be taken into consideration at the time of purchase. For security reasons, the Connect module is permanently mounted to the e-bike, so it cannot be installed at a later time.

Everything you need to know about Connect can be found here

Frame size Diamant 28": 50, 55, 60 cm
Wave 28": 45, 50, 55 cm
Drive Unit Continental Prime, 48 V mid motor, 250 Watt
Display Continental Display incl. Bluetooth
Akku Continental Framebattery integrated, 600 Wh, 48 Volt, 12.5 Ah, down tube
max load 140 kg
Frame Aluminium 6061, Continental-Interface
Headset Acros AZX-212 tapered
Fork Suntour springfork, NCX-D LO
Rear derailleur Shimano Alfine
Front derailleur N.V.
Bremse Shimano BR-MT400 (160 mm) disc brake
Headlight Busch&Müller Lumotec IQ-XS, 70 LUX
Rear light Busch&Müller Toplight 2C
luggage carrier Racktime, stayless with spring
Saddle Selle Royal Essenza
Seat pillar Humpert, Atar, patent, Aluminium, 31,6 mm, 300 mm
Pedal Marwi SP-823 Aluminium
Stand Pletscher Comp Flex, rear kickstand
Chain guard Hebie 0372
Fender SKS, plastic
Wight 25,6 kg
Handlebar stem Humpert Ergotec Octopus 50, adjustable, 31,8 mm
Handlebar Humpert Ergotec City Cruiser
Handle Ergon GP1
gearshift lever Shimano Alfine
Break lever Shimano Acera, 3-Finger brake lever
Tyres Continental Contact Plus City, 47-622
Product data sheet
Gates Belt Drive – e-bike manufaktur

GATES BELT DRIVES

We have fitted some of our e-bikes with Gates' tried-and-trusted belt drive. As a result, complex lubrication and cleaning of chain and gears is now a thing of the past. This carbon-reinforced alternative to the chain is robust and requires little maintenance. In addition, the lightweight system has an impressively long service life. The lock washers also benefit from this solution: they are placed under less strain than with a chain drive.

Display – e-bike manufaktur

Display - everything in view

Lightweight and compact displays combine perfect legibility with ergonomic and intuitive operation. In addition to the display for the support level or charge status of the battery, the display offers numerous functions of a bicycle computer as well as a USB and Bluetooth interface. The clever automatic lighting mode is controlled by an integrated light sensor.

Dopouts – e-bike manufaktur

DROPOUTS WITH SOPHISTICATED FUNCTION AND HARMONIOUS APPEARANCE

The innovative dropout of our e-bikes offers an integrated mounting for a rear stand. In this way, the support can be installed quickly and easily. In addition, the multi-function drop-out end is equipped with an opening for the gate belt. This means it can be changed in no time at all. Thanks to its tidy appearance, the drop-out is a perfect match for the frame design.

harmonically integrated – e-bike manufaktur

HARMONICALLY INTEGRATED -
EVEN IN OUR WAVE FRAME

Alongside technology and quality, design is also a key factor in the perfect e-bike! The new 48V e-bike system from our partner Continental ensures a harmonious look as the battery is included within the frame. We have even been able to fully integrate the battery into our Wave frame. A new type of frame construction combined with a low centre of gravity promises optimum stability and ride comfort!
